Vertical HIFU HS-511

Combined with capacitive RF, better treatment results

Non-invasive, no downtime

ARM-A9 CPU, Android O/S

Vertical HIFU HS-511 supplier

What is HIFU ?

HIFU is a non‑surgical High Intensity Focused Ultrasound technology and unlike lasers and radio frequency, it delivers focused ultrasound energy at the specified depth (i.e.3.0mm/4.5mm SMAS layer) and at the focal point temperatures of 60‑70℃ are produced which stimulate the production of new collagen without damaging or disrupting the epidermal skin tissue. Clinical studies have shown that this temperature range is needed to stimulate new collagen production and by in effect by passing the nerve sensors in the epidermis the treatment is both essentially pain free & effective.

Multiple Advantages

● Non‑invasive HIFU for face & body treatment with different cartridges.
● Motor gear by matrix moving type from 1 line to multi‑lines selectable.
● Securable control system can distinguish different cartridge automatically.
● Professional mode with free setting parameter and 6 memory function key for saving data.
● Smart mode with limited energy and pre‑set parameters for simple & safe treatment.
● Multi‑lines cartridge with long life span of 20,000 lines.
● Handpiece with OLED screen
● RF ID management control design provides different business operation modes.

Application

● Lift eyebrows and tighten blows	● Lift and firm jowl area
● Reduce nasolabial folds	● Body sculpture
● Reduce crow's feet	● Soften smiles lines
● Improve appearance of neck	● Face & Body contouring

Specifications

Frequency	4MHz
Cartridge	Face: 1.5mm,3.0mm,4.5mm Body: 6mm,8mm,10mm,13mm,16mm
Gear lines	Multi‑lines selectable
Cartridge life	20,500 lines
Energy	0.2~3.0J
Length	5.0~25mm
Pitch length	1.0~5.0mm
Width	0~10mm
Pitch width	1.0~5.0mm
Capacitive RF tip dimension	Φ10mm, Φ30mm, Φ40mm, Φ50mm, Φ60mm, Φ70mm, Φ80mm *
Operate mode	Smart mode & professional mode
Operate interface	15" True color touch screen
Power supply	AC 100~240V , 50/60Hz
Dimension	5252129cm (LWH)
Weight	27Kgs
